Chameleon MPAS 2.0

The Modular Portable Antenna System (MPAS 2.0) is a concept allowing the radio operator to configure and deploy the antenna system in a variety of configurations to suit the needs of the operator. Some of the possible deployment configurations:

• Vertical Whip configuration using one or both whips
• Horizontal Whip configuration for NVIS operations
• Sloper wire configuration
• Inverted “V” wire configuration
• Inverted “L” wire configuration
• NVIS wire configuration
• Balcony Rail mount using one or both whips
• Vehicle Mounted (Stationary use only)
• Man-Pack Vertical Whip configuration

(see images with deployment configurations)

Chameleon MPAS 2.0 Antenna System Consists Of

• 1 X CHA HYBRID-MICRO or HYBRID-MINI
• 1 X 22.25 meter Wire Tinned Copper KEVLAR PTFE (Teflon) (-70°C to 150°C) wire
• 1 X 7,62 meter Wire Tinned Copper KEVLAR PTFE (Teflon) (-70°C to 150°C) wire
• 1 X CHA MIL 2.0 (2,87 meter Long)
• 1 X CHA MIL EXT 2.0 (2.68 meter Long)
• 1 X CHA SPIKE MOUNT
• 1 X CHA 15.2 meter Coax with RFI Choke
• 1 X CHA MILITARY BACKPACK (BAG MAY VARY IN SHAPE AND COLOR)
• 2 X 3/8-24 SS Nuts
• Stainless Steel Hardware

Chameleon MPAS 2.0 Specifications

• Frequency: 6M – 160M
• Power:
  • HYBRID MICRO-100w SSB Phone, 50w CW, 25w High Duty Cycle Digital Modes
  • HYBRID MINI-500w SSB Phone, 250w CW, 40w High Duty Cycle Digital Modes
• Mounting Configuration: 3/8-24 Thread
• Weight: 3.63 Kg (8 lbs) without bag

Chameleon MPAS 2.0 Video Reviews

IT’S IMPORTANT TO WATERPROOF THE CHA MIL EXT 2.0 AND MIL WHIP 2.0 BEFORE PERMANENT INSTALLATION TO PREVENT OXIDATION IN THE WHIP JOINTS

Use  Ideal NOALOX Anti-Oxidant Compound or other similar product to improve the efficiency of aluminum conductor connections. This compound provides additional inner-strand and inner-conductor current paths.

USER GUIDE
